48V 105Ah Smart LiFePO4 Battery | 6,500+ Cycle Life

A long-life 48V 105Ah LiFePO4 battery with 5,376Wh capacity and 6,500+ cycles, designed to provide stable, reliable power for AGVs, sightseeing carts, golf carts, and heavy-duty electric vehicles.

Grade-A LiFePO4 Cells
6,500+ Cycle Life
5,376Wh High Capacity
MOQ: 10 units
Lead Time: 15–25 days

Inquire Now

Description SPECS FAQS

Previous Next

Product Overview

The TP48V105Ah is a versatile 48V 105Ah LiFePO4 battery designed to balance energy capacity, compact installation, and long-term reliability. Multiple PACK configurations help optimize the battery’s weight and dimensions while increasing energy density, allowing more energy to be stored within limited installation space.

Built with stable lithium iron phosphate chemistry and a high-quality protection system, the battery provides reliable safety and performance throughout the charge and discharge cycle. Its standardized 460 × 304 × 252 mm design can replace compatible lead-acid battery configurations, making it suitable for material handling equipment and medium- to large-sized electric vehicles.

Key Features

6,500+ Cycle Life: With a rated cycle life of more than 6,500 cycles, this LiFePO4 battery can deliver significantly longer service life than conventional lead-acid batteries, helping reduce battery replacement and long-term operating costs.
Comprehensive BMS Protection: Integrated PCM and Battery Management System (BMS) provide cell balancing, overcharge, over-discharge, and short-circuit protection for reliable battery operation.
High-Rate Discharge: Supports continuous high-current output to meet the power demands of AGVs, electric forklifts, and material handling vehicles with frequent starts, stops, and heavy loads.
Smart Communication & Monitoring: Supports RS485/UART communication, with optional Bluetooth or LCD display for real-time battery status monitoring and intelligent battery management.

Application Scenarios

Industrial Equipment: AGV Material Handling Vehicles, Electric Forklifts, Smart Robots
Commercial Vehicles: 4–8 Seater Electric Sightseeing Carts, Golf Carts, Electric Street Sweepers
Heavy-Duty Transportation: Electric Cargo Tricycles, Delivery Vehicles

Why Choose This Lithium Ion Battery?

This battery uses advanced nickel-manganese-cobalt chemistry, delivering 20% higher energy density compared to LiFePO4 (LFP). It works reliably across a wide temperature range, from -20°C to +60°C, making it a safe lithium ion battery for both extreme cold and hot conditions.

Higher Energy Density: 20% more capacity than LiFePO4 in the same size.
Wide Temperature Range: Operates from -20°C to +60°C without losing stability.
Fast Charging: Standard 3A charging (4–6 hours full) or optional 5A fast charging (just 2.5 hours).
Cost-Effective: Over a 5-year period, the per-charge cost is as low as $0.05, four times cheaper than lead-acid.
Eco-Friendly: Fully recyclable and compliant with EU ELV standards, reducing heavy metal pollution and supporting sustainable supply chains.

Item	48V 105Ah
Product Dimensions	460304252mm
Product weight	46.0±2kg
Material system	LiFePO4
Nominal voltage	51.2V
Nominal Capacity	105Ah
Configuration	16S1P
Nominal energy	5376Wh
IP Rating	IP55
Communication	4G/RS485/UART
Optional Features	Bluetooth / Display / Low-Temperature Preheating
